Bumpers

ColourBlack

Tyres

Tyre Width205

Tyre Profile60

Tyre Speed RatingH

Tyre Load Index96

TypeConventional

Official Brochure Tyre SizeYes

Diameter16

Paint

TypeGloss

Door mirrors/cameras

TypeExternally Adjustable

Windscreen wipers

Intermittent WipeVariable

Wheels

Rim TypeSteel

Rim Diameter (in)16

Rim Width (in)6.5

Spare wheel

TypeFull Size

Rim TypeSteel

External dimensions

Overall Length (mm)4418

Overall Width (mm)1835

Overall Height (mm)1861

Ground Clearance Unladen (mm)152

Wheelbase (mm)2662

Front Track (mm)1568

Rear Track (mm)1585

Kerb To Kerb Turning Circle (mm)11300

Wall To Wall Turning Circle (mm)11700

Rear Overhang (mm)878

Overall Length (in)173.9

Overall Width (in)72.2

Overall Height (in)73.3

Ground Clearance Unladen (lbs)6

Wheelbase (in)104.8

Front Track (in)61.7

Rear Track (in)62.4

Kerb To Kerb Turning Circle (ft)37.1

Wall To Wall Turning Circle (ft)38.4

Rear Overhang (in)34.6

Cargo area dimensions

Length (mm)1753

Width (mm)1538

Width Between Arches (mm)1226

Height (mm)1269

Loading Floor Height (mm)599

Loadspace Volume (l)2900

Measurement StandardSAE

Length (in)69

Width (in)60.6

Width Between Arches (in)48.3

Height (in)50

Loading Floor Height (in)23.6

Loadspace Volume (cu Ft)102.4

Cargo doors

OperationDouble Hinged

Width (mm)1248

Height (mm)1136

Opening Angle180

Width (in)49.1

Height (in)44.7

Fuel tanks

TypeMain

Capacity (l)60

Capacity (gal)15.9

Capacity (UK Gallons)13.2

Bulkhead

WidthFull

HeightFull

TypeSolid

Weights

Gross Vehicle Weight (kg)2005

Published Kerb Weight (kg)1407

Gross Trailer Weight Braked (kg)1200

Gross Trailer Weight Unbraked (kg)725

Front Axle Weight (kg)1125

Rear Axle Weight (kg)1050

Payload Allowance (kg)598

Payload Inc DriverYes

Payload Inc Driver (kg)598

Gross Vehicle Weight (lbs)4420

Published Kerb Weight (lbs)3102

Gross Trailer Weight Braked (lbs)2646

Gross Trailer Weight Unbraked (lbs)1598

Front Axle Weight (lbs)2480

Rear Axle Weight (lbs)2315

Payload Allowance (lbs)1318

Payload Inc Driver (lbs)1318

Disc brakes

Number Of4

Number Of Ventilated Discs2

Headlights

Lens TypeComplex Surface

Bulb Type (low Beam)Halogen

Bulb Type (high Beam)Halogen

Headlight control

Height AdjustmentManual

Head restraints

Height AdjustableYes

Number2

Front seat belts

Seat PositionPassenger

Pre-tensionersYes

Height AdjustableYes

Limited slip differential

TypeElectronic

Engine

Cc1560

Litres1.6

Bore75

Stroke88.3

Compression Ratio16

Number Of Cylinders4

ConfigurationIn-line

Valve Gear TypeOverhead Cam

Number Of Valves Per Cylinder2

Compressor

CompressorTurbo

Emission control level

Standard MetEU5

CO2 Level - G/km Combined124

Fuel system

Injection/carburationDiesel Common Rail

Fuel

Fuel TypeDiesel

Generic Primary Fuel TypeDiesel

Performance

Maximum Speed (km/h)145

Maximum Speed (mph)90

Power

Measurement StandardISO

Maximum Power KW55

Maximum Power Hp/PS75

Rpm For Maximum Power (low)3500

Maximum Torque Nm220

Rpm For Maximum Torque (low)1500

Primary Or Secondary Fuel Power FigurePrimary

Suspension

TypeBeam

Anti-roll BarYes

Wheel DependenceSemi-independent

Spring TypeCoil

Traffic light coding

Efficiency LabelD

Main service

Distance (km)32187

Period (mths)12

Distance (miles)20000

Fuel consumption

StandardECE 99/100

Urban (l/100km)5.5

Country/highway (l/100km)4.3

Combined (l/100km)4.8

Urban (km/l)18.2

Country/highway (km/l)23.3

Combined (km/l)20.8

Combined Vehicle Range (km)1250

Combined Vehicle Range (miles)777

Urban (mpg)43

Country/highway (mpg)55

Combined (mpg)49

Urban (miles Per UK Gallon)51

Country/highway (miles Per UK Gallon)66

Combined (miles Per UK Gallon)59

Powertrain type

TypeCombustion

Insurance

Description4E-T2
