Aerial

TypeRoof

Side rubbing strip

ColourBlack/grey

Bumpers

ColourBlack

Tyres

Tyre Width195

Tyre Profile70

Tyre Speed RatingT

Tyre Load Index100

TypeConventional

Official Brochure Tyre SizeYes

Diameter15

Paint

TypeMetallic

Door mirrors/cameras

TypeElectrically Adjustable

HeatedYes

Windscreen wipers

Intermittent WipeVariable

Rain SensorYes

Wheels

Rim TypeSteel

Rim Diameter (in)15

Rim Width (in)5.5

Spare wheel

TypeFull Size

Rim TypeSteel

External dimensions

Overall Length (mm)4863

Overall Width (mm)1974

Overall Height (mm)2070

Wheelbase (mm)2933

Kerb To Kerb Turning Circle (mm)10800

Wall To Wall Turning Circle (mm)11400

Rear Overhang (mm)997

Overall Length (in)191.5

Overall Width (in)77.7

Overall Height (in)81.5

Wheelbase (in)115.5

Kerb To Kerb Turning Circle (ft)35.4

Wall To Wall Turning Circle (ft)37.4

Rear Overhang (in)39.3

Cargo area dimensions

Length (mm)2582

Width (mm)1762

Width Between Arches (mm)1390

Height (mm)1430

Loading Floor Height (mm)619

Loadspace Volume (l)6550

Measurement StandardSAE

Length (in)101.7

Width (in)69.4

Width Between Arches (in)54.7

Height (in)56.3

Loading Floor Height (in)24.4

Loadspace Volume (cu Ft)231.3

Cargo doors

OperationDouble Hinged

Width (mm)1540

Height (mm)1370

Opening Angle180

Width (in)60.6

Height (in)53.9

Fuel tanks

TypeMain

Capacity (l)80

LPG/CNG Capacity (Kg)0

Capacity (gal)21.1

Capacity (UK Gallons)17.6

Bulkhead

WidthFull

HeightFull

TypeSolid

Weights

Gross Vehicle Weight (kg)2625

Published Kerb Weight (kg)1728

Front Axle Weight (kg)1450

Rear Axle Weight (kg)1475

Payload Allowance (kg)897

Payload Inc DriverYes

Payload Inc Driver (kg)897

Gross Vehicle Weight (lbs)5787

Published Kerb Weight (lbs)3810

Front Axle Weight (lbs)3197

Rear Axle Weight (lbs)3252

Payload Allowance (lbs)1978

Payload Inc Driver (lbs)1978

Disc brakes

Number Of4

Number Of Ventilated Discs2

Electronic traction control

Controlled ByABS & Engine Management

Headlights

Bulb Type (low Beam)Halogen

Headlight control

Dusk SensorYes

Height AdjustmentManual

Head restraints

Height AdjustableYes

Number3

Front seat belts

Seat PositionCentre

Pre-tensionersYes

Height AdjustableYes

Engine

Cc2198

Litres2.2

Bore86

Stroke94.6

Number Of Cylinders4

ConfigurationIn-line

Valve Gear TypeDouble Overhead Cam

Number Of Valves Per Cylinder4

Engine CodeEN CY

Compressor

CompressorTurbo

Emission control level

Standard MetEU5

CO2 Level - G/km Combined189

Fuel system

Injection/carburationDiesel Common Rail

Fuel

Fuel TypeDiesel

Generic Primary Fuel TypeDiesel

Power

Measurement StandardISO

Maximum Power KW92

Maximum Power Hp/PS125

Rpm For Maximum Power (low)3500

Maximum Torque Nm330

Rpm For Maximum Torque (low)1350

Primary Or Secondary Fuel Power FigurePrimary

Suspension

TypeBeam

Anti-roll BarYes

Wheel DependenceRigid

Spring TypeLeaf

Intermediate service

Distance (km)30000

Period (mths)12

Distance (miles)18641

Main service

Distance (km)60000

Period (mths)24

Distance (miles)37282

Fuel consumption

StandardECE 99/100

Urban (l/100km)8.5

Country/highway (l/100km)6.4

Combined (l/100km)7.2

Urban (km/l)11.8

Country/highway (km/l)15.6

Combined (km/l)13.9

Combined Vehicle Range (km)1111

Combined Vehicle Range (miles)690

Urban (mpg)28

Country/highway (mpg)37

Combined (mpg)33

Urban (miles Per UK Gallon)33

Country/highway (miles Per UK Gallon)44

Combined (miles Per UK Gallon)39

Powertrain type

TypeCombustion
