Aerial

TypeRoof

Side rubbing strip

ColourBlack/grey

Bumpers

ColourBlack

Tyres

TypeConventional

Official Brochure Tyre SizeYes

Paint

TypeGloss

Door mirrors/cameras

TypeExternally Adjustable

Indicator LightsYes

Windscreen wipers

Intermittent WipeVariable

Wheels

Rim TypeSteel

External dimensions

Overall Length (mm)5981

Overall Width (mm)2059

Overall Height (mm)2786

Wheelbase (mm)3750

Front Track (mm)1732

Rear Track (mm)1743

Kerb To Kerb Turning Circle (mm)13300

Wall To Wall Turning Circle (mm)13900

Rear Overhang (mm)1208

Overall Length (in)235.5

Overall Width (in)81.1

Overall Height (in)109.7

Wheelbase (in)147.6

Front Track (in)68.2

Rear Track (in)68.6

Kerb To Kerb Turning Circle (ft)43.6

Wall To Wall Turning Circle (ft)45.6

Rear Overhang (in)47.6

Cargo area dimensions

Length (mm)3494

Width (mm)1784

Width Between Arches (mm)1392

Height (mm)2025

Loading Floor Height (mm)684

Loadspace Volume (l)12400

Measurement StandardSAE

Length (in)137.6

Width (in)70.2

Width Between Arches (in)54.8

Height (in)79.7

Loading Floor Height (in)26.9

Loadspace Volume (cu Ft)437.9

Cargo doors

OperationDouble Hinged

Width (mm)1565

Height (mm)1887

Opening Angle180

Width (in)61.6

Height (in)74.3

Fuel tanks

TypeMain

Capacity (l)80

Capacity (gal)21.1

Capacity (UK Gallons)17.6

Bulkhead

WidthFull

HeightFull

TypeSolid

Weights

Gross Vehicle Weight (kg)3500

Published Kerb Weight (kg)2244

Gross Trailer Weight Braked (kg)2800

Gross Trailer Weight Unbraked (kg)750

Front Axle Weight (kg)1850

Rear Axle Weight (kg)2250

Payload Allowance (kg)1256

Manufacturer Driver Weight (kg)75

Payload Inc DriverYes

Payload Inc Driver (kg)1256

Kerb Weight Inc Driver (kg)2319

Measurement StandardDIN

Gross Vehicle Weight (lbs)7716

Published Kerb Weight (lbs)4947

Gross Trailer Weight Braked (lbs)6173

Gross Trailer Weight Unbraked (lbs)1653

Front Axle Weight (lbs)4079

Rear Axle Weight (lbs)4960

Payload Allowance (lbs)2769

Manufacturer Driver Weight (lbs)165

Payload Inc Driver (lbs)2769

Kerb Weight Inc Driver (lbs)5113

Disc brakes

Number Of4

Number Of Ventilated Discs2

Electronic traction control

Controlled ByABS & Engine Management

Headlights

Lens TypeComplex Surface

Bulb Type (low Beam)Halogen

Bulb Type (high Beam)Halogen

Headlight control

Height AdjustmentManual

Head restraints

Height AdjustableYes

Number3

Front seat belts

Seat PositionCentre

Pre-tensionersYes

Height AdjustableYes

Engine

Cc2198

Litres2.2

Bore86

Stroke94.6

Number Of Cylinders4

ConfigurationIn-line

Valve Gear TypeDouble Overhead Cam

Number Of Valves Per Cylinder4

Engine CodeEN CY

Compressor

CompressorTurbo

Emission control level

Standard MetEU5

CO2 Level - G/km Combined255

Fuel system

Injection/carburationDiesel Common Rail

Fuel

Fuel TypeDiesel

Generic Primary Fuel TypeDiesel

Power

Measurement StandardISO

Maximum Power KW92

Maximum Power Hp/PS125

Rpm For Maximum Power (low)3500

Maximum Torque Nm350

Rpm For Maximum Torque (low)1450

Primary Or Secondary Fuel Power FigurePrimary

Suspension

TypeBeam

Anti-roll BarYes

Wheel DependenceRigid

Spring TypeLeaf

Main service

Distance (km)48280

Period (mths)24

Distance (miles)30000

Fuel consumption

StandardECE 99/100

Urban (l/100km)8.5

Country/highway (l/100km)9.7

Combined (l/100km)8.7

Urban (km/l)11.8

Country/highway (km/l)10.3

Combined (km/l)11.5

Combined Vehicle Range (km)920

Combined Vehicle Range (miles)572

Urban (mpg)28

Country/highway (mpg)24

Combined (mpg)27

Urban (miles Per UK Gallon)33

Country/highway (miles Per UK Gallon)29

Combined (miles Per UK Gallon)33

Powertrain type

TypeCombustion
