Aerial

TypeRoof

Side rubbing strip

ColourBody Colour

Bumpers

ColourPainted

Tyres

Tyre Width215

Tyre Profile65

Tyre Speed RatingR

Tyre Load Index109

TypeConventional

Official Brochure Tyre SizeYes

Diameter16

Paint

TypeGloss

Door mirrors/cameras

TypeElectrically Adjustable

HeatedYes

Electrically foldable mirrors

OperationElectric

Windscreen wipers

Intermittent WipeAutomatic

Rain SensorYes

Wheels

Rim TypeAlloy

Rim Diameter (in)16

Rim Width (in)6.5

Spare wheel

TypeFull Size

Rim TypeSteel

External dimensions

Overall Length (mm)4972

Overall Width (mm)1986

Overall Height (mm)2020

Wheelbase (mm)2933

Front Track (mm)1745

Rear Track (mm)1718

Kerb To Kerb Turning Circle (mm)11600

Wall To Wall Turning Circle (mm)12200

Rear Overhang (mm)1028

Overall Length (in)195.7

Overall Width (in)78.2

Overall Height (in)79.5

Wheelbase (in)115.5

Front Track (in)68.7

Rear Track (in)67.6

Kerb To Kerb Turning Circle (ft)38.1

Wall To Wall Turning Circle (ft)40

Rear Overhang (in)40.5

Cargo area dimensions

Length (mm)2555

Width (mm)1775

Width Between Arches (mm)1390

Height (mm)1406

Loading Floor Height (mm)583

Loadspace Volume (l)5950

Measurement StandardSAE

Length (in)100.6

Width (in)69.9

Width Between Arches (in)54.7

Height (in)55.4

Loading Floor Height (in)23

Loadspace Volume (cu Ft)210.1

Cargo doors

OperationDouble Hinged

Width (mm)1400

Height (mm)1340

Opening Angle180

Width (in)55.1

Height (in)52.8

Fuel tanks

TypeMain

Capacity (l)80

LPG/CNG Capacity (Kg)0

Capacity (gal)21.1

Capacity (UK Gallons)17.6

Bulkhead

WidthFull

HeightFull

TypeSolid

Weights

Gross Vehicle Weight (kg)2700

Published Kerb Weight (kg)1793

Gross Trailer Weight Braked (kg)2000

Gross Trailer Weight Unbraked (kg)750

Front Axle Weight (kg)1550

Rear Axle Weight (kg)1400

Payload Allowance (kg)907

Payload Inc DriverYes

Payload Inc Driver (kg)907

Gross Vehicle Weight (lbs)5953

Published Kerb Weight (lbs)3953

Gross Trailer Weight Braked (lbs)4409

Gross Trailer Weight Unbraked (lbs)1653

Front Axle Weight (lbs)3417

Rear Axle Weight (lbs)3086

Payload Allowance (lbs)2000

Payload Inc Driver (lbs)2000

Disc brakes

Number Of4

Number Of Ventilated Discs2

Parking distance sensors

TypeSensor & Camera

Parking distance system

TypeSensor & Camera

Electronic traction control

Controlled ByABS & Engine Management

Headlights

Bulb Type (low Beam)Halogen

Headlight control

Dusk SensorYes

Height AdjustmentManual

Front airbag

Occupant Switch OffYes

Head restraints

Height AdjustableYes

Number3

Front seat belts

Seat PositionCentre

Pre-tensionersYes

Height AdjustableYes

Anti-theft protection

Interior MonitoringYes

Engine

Cc2198

Litres2.2

Bore86

Stroke94.6

Compression Ratio15.5

Number Of Cylinders4

ConfigurationIn-line

Valve Gear TypeDouble Overhead Cam

Number Of Valves Per Cylinder4

Engine CodeEN-CY

Compressor

CompressorTurbo

Emission control level

Standard MetEU5

CO2 Level - G/km Combined186

Fuel system

Injection/carburationDiesel Common Rail

Fuel

Fuel TypeDiesel

Generic Primary Fuel TypeDiesel

Power

Measurement StandardISO

Maximum Power KW92

Maximum Power Hp/PS125

Rpm For Maximum Power (low)3500

Maximum Torque Nm350

Rpm For Maximum Torque (low)1450

Primary Or Secondary Fuel Power FigurePrimary

Suspension

TypeBeam

Anti-roll BarYes

Wheel DependenceRigid

Spring TypeLeaf

Main service

Distance (km)50000

Period (mths)24

Distance (miles)31069

Fuel consumption

StandardECE 99/100

Urban (l/100km)8.1

Country/highway (l/100km)6.4

Combined (l/100km)7

Urban (km/l)12.3

Country/highway (km/l)15.6

Combined (km/l)14.3

Combined Vehicle Range (km)1143

Combined Vehicle Range (miles)710

Urban (mpg)29

Country/highway (mpg)37

Combined (mpg)34

Urban (miles Per UK Gallon)35

Country/highway (miles Per UK Gallon)44

Combined (miles Per UK Gallon)40

Powertrain type

TypeCombustion

Insurance

Description8E-T1
