Aerial

TypeRoof

Side rubbing strip

ColourBlack/grey

Bumpers

ColourBlack

Tyres

Tyre Width195

Tyre Profile65

Tyre Speed RatingT

TypeConventional/summer

Diameter15

Paint

TypeGloss

Door mirrors/cameras

TypeElectrically Adjustable

HeatedYes

Windscreen wipers

Intermittent WipeAutomatic

Wheels

Rim TypeSteel

Rim Diameter (in)15

Rim Width (in)6

Spare wheel

TypeFull Size

Rim TypeSteel

External dimensions

Overall Length (mm)4321

Overall Width (mm)1829

Overall Height (mm)1816

Wheelbase (mm)2697

Front Track (mm)1521

Rear Track (mm)1533

Kerb To Kerb Turning Circle (mm)10700

Wall To Wall Turning Circle (mm)11200

Rear Overhang (mm)709

Overall Length (in)170.1

Overall Width (in)72

Overall Height (in)71.5

Wheelbase (in)106.2

Front Track (in)59.9

Rear Track (in)60.4

Kerb To Kerb Turning Circle (ft)35.1

Wall To Wall Turning Circle (ft)36.7

Rear Overhang (in)27.9

Cargo area dimensions

Length (mm)1753

Width (mm)1460

Width Between Arches (mm)1219

Height (mm)1258

Loading Floor Height (mm)575

Loadspace Volume (l)3100

Measurement StandardVDA

Length (in)69

Width (in)57.5

Width Between Arches (in)48

Height (in)49.5

Loading Floor Height (in)22.6

Loadspace Volume (cu Ft)109.5

Cargo doors

OperationDouble Hinged

Width (mm)1219

Height (mm)1119

Opening Angle180

Width (in)48

Height (in)44.1

Fuel tanks

TypeMain

Capacity (l)60

Capacity (gal)15.9

Capacity (UK Gallons)13.2

Bulkhead

WidthFull

HeightFull

TypeSolid

Weights

Gross Vehicle Weight (kg)1950

Published Kerb Weight (kg)1315

Gross Trailer Weight Braked (kg)1050

Gross Trailer Weight Unbraked (kg)660

Front Axle Weight (kg)1080

Rear Axle Weight (kg)1070

Payload Allowance (kg)635

Kerb Weight Includes DriverYes

Manufacturer Driver Weight (kg)75

Payload Inc Driver (kg)710

Kerb Weight Inc Driver (kg)1315

Measurement StandardEU

Gross Vehicle Weight (lbs)4299

Published Kerb Weight (lbs)2899

Gross Trailer Weight Braked (lbs)2315

Gross Trailer Weight Unbraked (lbs)1455

Front Axle Weight (lbs)2381

Rear Axle Weight (lbs)2359

Payload Allowance (lbs)1400

Manufacturer Driver Weight (lbs)165

Payload Inc Driver (lbs)1565

Kerb Weight Inc Driver (lbs)2899

Disc brakes

Number Of4

Number Of Ventilated Discs2

Electronic traction control

Controlled ByABS & Engine Management

Headlights

Bulb Type (low Beam)Halogen

Headlight control

Height AdjustmentManual

Head restraints

Height AdjustableYes

Number2

Front seat belts

Seat PositionPassenger

Pre-tensionersYes

Height AdjustableYes

Engine

Cc1461

Litres1.5

Bore76

Stroke80.5

Compression Ratio15.5

Number Of Cylinders4

ConfigurationIn-line

Valve Gear TypeOverhead Cam

Number Of Valves Per Cylinder2

Engine CodeOM 607 DE15LA

Compressor

CompressorTurbo

Emission control level

Standard MetEU5

CO2 Level - G/km Combined123

Fuel system

Injection/carburationDiesel Common Rail

Fuel

Fuel TypeDiesel

Generic Primary Fuel TypeDiesel

Power

Measurement StandardEEC

Maximum Power KW66

Maximum Power Hp/PS90

Rpm For Maximum Power (low)4000

Maximum Torque Nm200

Rpm For Maximum Torque (low)1750

Primary Or Secondary Fuel Power FigurePrimary

Suspension

TypeTorsion Beam

Anti-roll BarYes

Wheel DependenceSemi-independent

Spring TypeCoil

Main service

Distance (km)38624

Period (mths)24

Distance (miles)24000

Fuel consumption

StandardECE 99/100

Urban (l/100km)5.2

Country/highway (l/100km)4.2

Combined (l/100km)4.6

Urban (km/l)19.2

Country/highway (km/l)23.8

Combined (km/l)21.7

Combined Vehicle Range (km)1304

Calculated Vehicle Range (km)1304

Combined Vehicle Range (miles)810

Calculated Vehicle Range (miles)810

Urban (mpg)45

Country/highway (mpg)56

Combined (mpg)51

Urban (miles Per UK Gallon)54

Country/highway (miles Per UK Gallon)67

Combined (miles Per UK Gallon)61

Powertrain type

TypeCombustion

Insurance

Description5E-T2
